If you own a 2013 Nissan Altima and are shopping for replacement wheels, upgrading to alloys, or wondering whether your Altima rims will bolt onto an EV like the Nissan Leaf, you need one critical measurement: the bolt pattern. This guide covers the exact 2013 Nissan Altima bolt pattern, hub bore, thread size, and torque specs — then shows how that same pattern crosses over to today's electric vehicles for owners managing a mixed garage.
2013 Nissan Altima Bolt Pattern: The Exact Specs
The 2013 Nissan Altima (seventh generation, L33 chassis) uses a 5x114.3 mm bolt pattern — also written as 5x4.5 inches in imperial notation. This means five lug bolts arranged on a circle with a 114.3 mm (4.5-inch) diameter. This pattern is one of the most common in the automotive world, shared across dozens of Nissan, Toyota, Honda, Hyundai, and Kia models spanning decades.
| Specification | Value |
|---|---|
| Bolt Pattern | 5 x 114.3 mm (5 x 4.5 in) |
| Center Bore (Hub Bore) | 66.1 mm |
| Lug Thread Size | M12 x 1.25 |
| Lug Nut Torque Spec | 80 lb-ft (108 Nm) |
| Stock Wheel Sizes | 16" (2.5 S), 17" (2.5 SV/SL), 18" (3.5 SL) |
| Stock Tire Sizes | 215/60R16, 215/55R17, 235/45R18 |
| Offset (ET) | +40 to +45 mm (varies by wheel) |
The 66.1 mm center bore is equally important. Wheels must either match this bore exactly (hub-centric fitment) or use hub-centric rings to avoid vibration. A wheel with a larger center bore will physically mount but can cause steering shake at highway speeds without rings. A wheel with a smaller bore simply won't fit over the Altima's hub.
Why Bolt Pattern Matters for Mixed EV and Gas Garages
Here's where this gets practical for EV owners. The 5x114.3 bolt pattern is shared by the Nissan Leaf (all generations, 2011–present), meaning wheels can physically interchange between a 2013 Altima and a Leaf — with caveats. If you're rotating a winter wheel-and-tire set between vehicles, selling take-off alloys, or sourcing used wheels, knowing this shared pattern opens up options.
However, bolt pattern alone doesn't guarantee fitment. You must also match:
- Center bore: The Leaf also uses a 66.1 mm hub bore, so direct swaps work without rings.
- Offset: The Leaf's stock offset is typically +40 mm, close to the Altima's range. Significant offset differences can cause rubbing on suspension components or fender liners.
- Load rating: EVs are heavier than their gas counterparts. A Leaf (3,300–3,600 lbs curb weight) demands wheels rated for that load. Lightweight Altima take-offs may carry a lower load rating than ideal for EV use.
- Wheel diameter clearance: Brake caliper size varies; an 18" Altima wheel may clear Leaf calipers, but a 16" may not on certain Leaf trims.
Bolt Pattern Cross-Reference: EVs Sharing 5x114.3
The 5x114.3 pattern is widespread. Below is a cross-reference of electric and plug-in hybrid vehicles that share this bolt pattern — useful if you're managing wheels across a multi-vehicle household or considering a used EV wheel purchase.
| Vehicle | Center Bore | Thread Size | Notes |
|---|---|---|---|
| Nissan Leaf (2011–2026) | 66.1 mm | M12 x 1.25 | Direct Altima cross-fit |
| Hyundai Ioniq 5 (2022–2026) | 67.1 mm | M14 x 1.5 | Different bore/thread — rings + new lugs needed |
| Hyundai Ioniq 6 (2023–2026) | 67.1 mm | M14 x 1.5 | Same as Ioniq 5 |
| Kia EV6 (2022–2026) | 67.1 mm | M14 x 1.5 | Same platform as Ioniq 5 |
| Toyota bZ4X (2023–2026) | 54.1 mm | M12 x 1.5 | Smaller bore — will NOT fit Altima hubs |
| Toyota RAV4 Prime (PHEV) | 54.1 mm | M12 x 1.5 | Smaller bore — not compatible |
| Honda Clarity PHEV (2017–2021) | 64.1 mm | M12 x 1.5 | Different bore and thread pitch |
Key takeaway: even when the bolt pattern matches, center bore and thread size often differ between brands. Always verify all three dimensions — pattern, bore, and thread — before purchasing wheels for cross-vehicle use.
How to Measure and Verify Your Bolt Pattern
If you're confirming the bolt pattern on your 2013 Altima (or any 5-lug vehicle), here's the method:
- Count the lugs: The Altima has 5 lug bolts per wheel.
- Measure the circle diameter: For a 5-lug pattern, measure from the center of one lug to the far edge of the lug directly across (skipping one). This gives the bolt circle diameter.
- Result: You should get 114.3 mm (4.5 inches).
Unlike 4-lug or 6-lug patterns where you measure center-to-center across the hub, 5-lug measurement requires this skip-one technique because no two lugs sit directly opposite each other. A dedicated bolt pattern gauge (under $15) removes guesswork.
Torque Specs and Lug Nut Safety
The 2013 Altima's lug nuts should be torqued to 80 lb-ft (108 Nm) in a star pattern. This matters especially when swapping to aftermarket wheels or when using impact wrenches at tire shops, which frequently overtighten and can stretch studs or warp rotors.
For EV owners cross-fitting wheels: the Leaf uses the same M12 x 1.25 thread and a nearly identical torque spec (80 lb-ft). However, Hyundai/Kia EVs using M14 x 1.5 studs require different lug nuts entirely and a higher torque spec (typically 100–110 lb-ft). Never use Altima lug nuts on a Hyundai or Kia EV — the thread pitch and diameter are incompatible.
Wheel Upgrade Considerations: Weight, Efficiency, and EV Impact
Upgrading from the Altima's stock 16-inch steel wheels (approximately 22 lbs each) to lighter alloys saves unsprung weight and can marginally improve ride quality. But if you're fitting those same alloys onto a Leaf or other EV, consider:
- Range impact: Larger, heavier wheels increase rotational mass and rolling resistance. On a Leaf, moving from 16" to 18" wheels typically costs 5–10 miles of EPA range. On the 2013 Altima, the fuel economy penalty is roughly 1–2 MPG combined, per fueleconomy.gov data.
- Tire selection: EV-specific tires (like the Michelin Energy Saver A/S or Hankook iON) use low-rolling-resistance compounds that preserve range. Standard all-season tires on an Altima-sourced wheel may reduce Leaf efficiency by 3–5%.
- Aero wheel covers: Some EV wheels use flush aero covers to reduce drag. Altima alloys lack this feature, which matters more at highway speeds where aero drag dominates energy consumption.
Where to Source Compatible Wheels and Verify Fitment
For the 2013 Altima bolt pattern (5x114.3, 66.1 mm bore), compatible wheels are abundant:
- OEM Nissan take-offs: Wheels from 2013–2018 Altima, 2016–2023 Maxima, and 2011–2026 Leaf are direct-fit.
- Aftermarket: Brands like Enkei, Konig, and TSW produce 5x114.3 wheels in various offsets. Confirm the center bore is 66.1 mm or larger (use rings if larger).
- Used market: Verify part numbers against Nissan's official parts catalog or measure physically before purchasing.
For EV-specific wheel purchases, check the wheel's load rating. A Nissan Leaf SV Plus (2026) has a curb weight around 3,640 lbs, meaning each wheel should be rated for at least 1,100 lbs. Many lightweight aftermarket wheels designed for sport compacts fall below this threshold.
Frequently Asked Questions
What is the bolt pattern for a 2013 Nissan Altima?
The 2013 Nissan Altima uses a 5x114.3 mm (5x4.5 inch) bolt pattern with a 66.1 mm center bore and M12 x 1.25 lug thread. This pattern is shared with the Nissan Leaf and many other Nissan, Toyota, Honda, and Hyundai vehicles.
Will 2013 Altima wheels fit a Nissan Leaf?
Yes, the bolt pattern (5x114.3) and center bore (66.1 mm) are identical between the 2013 Altima and all Nissan Leaf generations. Verify offset and load rating before swapping — the Leaf's heavier curb weight may exceed the load rating of lightweight Altima steel wheels.
Can I put Hyundai Ioniq 5 wheels on my 2013 Altima?
The Ioniq 5 shares the 5x114.3 bolt pattern, but its center bore is 67.1 mm (larger than the Altima's 66.1 mm) and it uses M14 x 1.5 lug studs instead of M12 x 1.25. You would need hub-centric rings and different lug nuts, making it impractical for most owners.
What is the lug nut torque for a 2013 Altima?
Nissan specifies 80 lb-ft (108 Nm) for the 2013 Altima. Always torque in a star pattern and re-check after 50 miles when installing new wheels. Avoid impact wrenches set above this spec to prevent stud stretching.
Does changing wheel size affect my Altima's fuel economy or an EV's range?
Yes. Larger and heavier wheels increase rolling resistance and rotational mass. On the 2013 Altima, moving from 16" to 18" wheels typically costs 1–2 MPG combined. On a Nissan Leaf, the same change can reduce EPA range by 5–10 miles. Stick with the OEM wheel diameter for optimal efficiency.
