The 2017 Honda Accord Bolt Pattern: Exact Specs
The 2017 Honda Accord uses a 5x114.3 mm bolt pattern (also expressed as 5x4.5 inches). This is one of the most common bolt patterns in the automotive world, shared across dozens of Honda, Toyota, Nissan, and Hyundai models. Whether you're replacing a damaged wheel, upgrading to aftermarket alloys, or evaluating this chassis for an EV conversion project, knowing the precise hub specifications is essential.
| Specification | Value |
|---|---|
| Bolt Pattern (PCD) | 5x114.3 mm (5x4.5") |
| Center Bore | 64.1 mm |
| Thread Size (Lug Nut) | M12 x 1.5 |
| Lug Nut Torque Spec | 80 lb-ft (108 Nm) |
| Stock Wheel Sizes | 16", 17", or 18" depending on trim |
| Stock Tire Sizes | 215/60R16, 225/50R17, 235/45R18 |
| Wheel Offset (ET) | +45 to +55 mm (varies by wheel size) |
The 64.1 mm center bore is a Honda-specific dimension. If you're fitting aftermarket wheels with a larger bore (common with many universal-fit options), you'll need hub-centric rings — typically 64.1 mm outer to whatever the wheel's bore is (e.g., 73.1 mm). Skipping these rings causes vibration at highway speeds, as the wheel isn't properly centered on the hub.
Why the 5x114.3 Bolt Pattern Matters for Wheel Shopping
The 5x114.3 bolt pattern is shared by a wide range of vehicles, which makes finding compatible wheels relatively easy. Vehicles sharing this pattern include:
- Honda Civic (2016+), CR-V, Pilot, Odyssey
- Toyota Camry, RAV4, Highlander
- Nissan Altima, Maxima, Rogue
- Hyundai Sonata, Tucson, Santa Fe
- Kia K5, Sportage, Sorento
- Ford Mustang (2015+), Edge, Escape
However, bolt pattern alone does not determine fitment. You must also match or accommodate the center bore, offset, and wheel width. A Mustang wheel may bolt onto an Accord hub, but if the offset is too aggressive, it will rub the fender liner or strut. Always cross-reference offset and width before purchasing.
2017 Accord Trim Levels and Stock Wheel Sizes
The 2017 Accord was the final model year of the ninth generation (CR1/CR2/CR3 chassis). Honda offered it in several trims, each with specific wheel and tire packages:
| Trim | Wheel Size | Tire Size | Wheel Type |
|---|---|---|---|
| LX / LX-S | 16" x 7.0J | 215/60R16 | Steel w/ cover or alloy |
| Sport / Sport Special Edition | 18" x 8.0J | 235/45R18 | Alloy |
| EX / EX-L | 17" x 7.5J | 225/50R17 | Alloy |
| Touring | 18" x 8.0J | 235/45R18 | Alloy |
The Sport and Touring trims with 18-inch wheels have slightly different offset values than the 16-inch and 17-inch setups. When sourcing replacement OEM wheels, always verify the part number matches your original trim's specifications to avoid clearance issues with brake calipers.
Torquing Lug Nuts: The 80 lb-ft Standard
Honda specifies 80 lb-ft (108 Nm) of torque for the 2017 Accord's M12 x 1.5 lug nuts. This is critical — over-torquing can stretch studs and warp brake rotors, while under-torquing risks wheel separation. Always use a calibrated torque wrench and follow a star-pattern tightening sequence.
If you're using aftermarket lug nuts (common when switching to lighter or conical-seat wheels), verify they match the M12 x 1.5 thread pitch. Many aftermarket wheels require conical (tapered) seat lug nuts rather than Honda's OEM flat-washer (mag) seat style. Using the wrong seat type creates an unsafe, point-load contact on the wheel.
The 2017 Accord vs. Modern EVs: A Platform Comparison
Since this is 2026, many Accord owners are evaluating whether to keep their ninth-gen or transition to an electric vehicle. While the Accord is a conventional ICE sedan, understanding how it compares to today's EVs in terms of running costs, performance, and practicality helps frame the decision.
| Metric | 2017 Accord 2.4L | 2026 Honda Prologue Elite |
|---|---|---|
| Powertrain | 2.4L I-4, CVT | Dual-motor AWD, BEV |
| Horsepower | 185 hp | 288 hp |
| 0-60 mph | ~7.5 sec | ~5.8 sec |
| EPA Efficiency | 27/36/30 MPG | 101 MPGe combined |
| EPA Range | ~450 mi (14.8 gal tank) | 290 mi (EPA est.) |
| Energy/Fuel Cost per 100 mi | ~$10.50 (gas at $3.50/gal) | ~$4.50 (electric at $0.15/kWh) |
| Bolt Pattern | 5x114.3 mm | 5x120 mm |
| Annual Maintenance (est.) | ~$450 | ~$150 |
| Base MSRP (when new / current) | ~$23,570 (2017) | $52,900 (2026) |
Notable difference: the 2026 Prologue uses a 5x120 mm bolt pattern (shared with its GM Ultium platform siblings like the Chevy Blazer EV and Cadillac Lyriq). This means wheels are not interchangeable between the old Accord and Honda's current EV lineup. If you've accumulated a set of quality Accord wheels, they won't carry over.
EV Conversion Considerations for the Ninth-Gen Accord
Some enthusiasts explore converting a 2017 Accord to electric power. The ninth-gen's front-wheel-drive layout, spacious engine bay, and relatively light curb weight (~3,200 lbs for the 4-cylinder) make it a candidate. However, several realities apply:
- Cost: A proper EV conversion with a NetGain Hyper9 or Cascadia Motion powertrain, plus a 30-50 kWh battery pack, typically runs $15,000-$30,000 in parts alone, before labor.
- Range: A 40 kWh pack in this chassis yields roughly 100-130 miles of real-world range — far below any production 2026 EV.
- Regulatory: Converted vehicles face inspection hurdles in many states and cannot qualify for the federal §30D EV tax credit.
- Resale: Converted vehicles typically depreciate more than stock, as buyers are wary of one-off engineering.
For most owners, trading into a production EV like the Honda Prologue, Hyundai Ioniq 6, or Tesla Model 3 offers better range, warranty coverage, and charging infrastructure access than a conversion project.
Wheel Upgrade Tips: What Fits the 5x114.3 Hub
If you're keeping your 2017 Accord and want to upgrade wheels, here are fitment guardrails that keep you safe and legal:
- Maximum recommended width: 8.5 inches (front and rear) on stock fenders without rubbing.
- Offset range: +35 to +50 mm keeps the wheel within the fender well. Lower offsets push the wheel outward and risk fender contact over bumps.
- Maximum diameter: 19-inch wheels with 235/35R19 tires clear the brakes and maintain speedometer accuracy, but ride quality degrades noticeably from the stock 16" or 17" setup.
- Weight matters: Heavier aftermarket wheels increase unsprung mass, worsening ride quality and slightly reducing fuel economy. Flow-formed or forged wheels in the 18-20 lb range per wheel are ideal.
Always ensure any aftermarket wheel has a load rating meeting or exceeding Honda's specification — typically 1,235 lbs per wheel for the Accord. Lightweight track-focused wheels sometimes fall below this threshold.
Frequently Asked Questions
Is the 2017 Honda Accord bolt pattern the same as the Civic?
Yes, for 2016 and newer Civics. The 10th-generation Civic (2016-2021) and the 2017 Accord both use a 5x114.3 mm bolt pattern with a 64.1 mm center bore. However, offsets differ — Civic wheels tend to have higher offset (+45 to +50) and narrower widths, so always verify before swapping.
Can I put Toyota Camry wheels on a 2017 Accord?
Many Camry model years (2012-2023) share the 5x114.3 bolt pattern and a 60.1 mm center bore. The center bore difference is the issue: Toyota's 60.1 mm bore is smaller than Honda's 64.1 mm hub, so Camry wheels physically will not slide onto an Accord hub. The reverse (Accord wheels on a Camry) works with hub-centric rings.
What size lug nuts does the 2017 Accord use?
M12 x 1.5 thread pitch with a flat-washer (mag) seat for OEM Honda wheels. If switching to aftermarket wheels with conical seats, you'll need matching conical-seat lug nuts in M12 x 1.5.
Does the 2017 Accord bolt pattern match any electric vehicles?
Very few. Most modern EVs use larger bolt patterns to accommodate heavier vehicles and larger brake assemblies. The Tesla Model 3 and Model Y use 5x114.3, so there is bolt-pattern compatibility — but Tesla's center bore is 64.1 mm as well, making select wheel swaps possible with offset verification. The Hyundai Ioniq 5 also uses 5x114.3 with a 67.1 mm bore (requiring rings for Accord fitment).
Should I upgrade to 18-inch wheels on my 2017 Accord LX?
From a pure fitment standpoint, 18x8 +45 wheels with 235/45R18 tires bolt on with no modifications. The tradeoff is ride comfort — the thinner sidewall transmits more road imperfections, and replacement tires cost roughly 30-40% more than the stock 215/60R16 size. If your priority is comfort and low operating cost, stay with 16s or 17s.
Sources: Honda News 2017 Accord Press Kit, fueleconomy.gov 2017 Accord
