Searches for the 2016 Tundra bolt pattern tend to come from truck owners planning wheel swaps, trailer towing, or — increasingly — electric-vehicle conversions and trailer-based EV accessories. While the 2016 Toyota Tundra is a gasoline V8 pickup (not an EV), understanding its wheel bolt pattern matters for anyone pairing it with an EV daily driver, using it to haul an EV-compatible trailer, or sourcing parts for an electrification project.
This guide covers the exact bolt specifications, explains real-world fitment implications for EV-adjacent use cases, and shows how the Tundra compares to today's electric pickups like the Ford F-150 Lightning, Rivian R1T, and Chevrolet Silverado EV when it comes to wheels, towing, and trailer compatibility.
2016 Tundra Bolt Pattern: Exact Specifications
The 2016 Toyota Tundra uses a 5-lug bolt pattern measuring 5x150mm (also written as 5x5.9 inches). This is one of the wider bolt-circle diameters found on any light-duty pickup, and it has been consistent across Tundra model years from 2007 through 2021 (the second-generation Tundra platform).
| Specification | Value |
|---|---|
| Bolt pattern (metric) | 5x150mm |
| Bolt pattern (imperial) | 5x5.9 in |
| Lug count | 5 |
| Center bore | 110.1mm |
| Lug nut thread size | M14 x 1.5 |
| Lug nut torque spec | 97 lb-ft (131 Nm) |
| Stock wheel sizes | 18 in (base/SR5), 20 in (Limited/Platinum) |
| Typical offset (ET) | +50mm to +60mm (varies by trim) |
The 5x150mm pattern is relatively uncommon in the aftermarket wheel world compared to the 6-lug patterns found on most modern half-ton pickups (Ford's 6x135mm, Chevy/GMC's 6x139.7mm, Toyota's own newer 6-lug Tacoma and 2022+ Tundra). This limits your wheel choices for the 2016 Tundra, which is worth knowing if you're sourcing wheels from a salvage yard or planning a custom setup.
Why Bolt Pattern Matters for EV Owners
At first glance, a gasoline truck's wheel spec might seem irrelevant to EV ownership. But several scenarios make this information directly useful:
Towing an EV or EV-Compatible Trailer
If you use a 2016 Tundra to flat-tow or trailer a disabled EV, or if you're hauling a purpose-built EV cargo trailer, matching the trailer's wheel bolt pattern to available spare wheels simplifies roadside repairs. Most EV-specific trailers use standard automotive bolt patterns (5x114.3mm or 5x120mm are common), which are not compatible with the Tundra's 5x150mm — meaning you'll need dedicated trailer spares, not shared wheels.
EV Conversion Projects
The second-generation Tundra (2007–2021) has become a candidate for aftermarket EV conversions due to its body-on-frame construction and generous engine bay. Shops performing these conversions sometimes upgrade the axle assemblies, and the 5x150mm bolt pattern must be preserved or deliberately changed (via hub adapters or axle swaps) to maintain wheel compatibility. Conversion shops like EV West and Legacy EV have documented the challenges of retaining OEM bolt patterns during drivetrain swaps.
Wheel Adapters and Hub-Centric Rings
Some EV owners who also maintain a Tundra as a tow vehicle want to standardize wheels across their fleet. Hub adapters that convert 5x150mm to other patterns exist but introduce safety concerns — added unsprung mass, altered offset, and potential stress on wheel bearings. For any vehicle, but especially for heavier EVs, hub adapters are generally discouraged for highway use.
How the Tundra's Bolt Pattern Compares to EV Trucks
Modern electric pickups have largely moved to 6-lug patterns to handle greater vehicle weight (EVs are typically 1,000–2,000 lbs heavier than their ICE counterparts due to battery packs). Here's how the 2016 Tundra compares:
| Vehicle | Bolt Pattern | Lug Count | Center Bore |
|---|---|---|---|
| 2016 Toyota Tundra | 5x150mm | 5 | 110.1mm |
| Ford F-150 Lightning (2022–2026) | 6x135mm | 6 | 87.1mm |
| Rivian R1T (2022–2026) | 6x139.7mm | 6 | 77.8mm |
| Chevrolet Silverado EV (2024–2026) | 6x139.7mm | 6 | 77.8mm |
| 2022+ Toyota Tundra (ICE/Hybrid) | 6x139.7mm | 6 | 110.1mm |
| GMC Hummer EV Pickup | 6x139.7mm | 6 | 77.8mm |
The shift to 6-lug patterns on EV trucks is driven by the need to distribute higher loads across more fasteners. The F-150 Lightning, for example, has a curb weight around 6,000–6,500 lbs depending on trim — roughly 1,000 lbs more than a comparable gas F-150. The 2016 Tundra, at roughly 5,000–5,500 lbs curb weight, was engineered for lower loads, allowing the 5-lug pattern to suffice.
2016 Tundra Towing Specs and EV Trailer Considerations
When pairing a 2016 Tundra with EV-related towing tasks, the truck's capacity matters as much as its bolt pattern:
- Maximum towing capacity: 10,500 lbs (properly equipped, 5.7L V8, CrewMax 4x2)
- Maximum payload: 1,730 lbs (varies by cab/bed/drivetrain configuration)
- Engine: 5.7L V8, 381 hp, 401 lb-ft torque
- Transmission: 6-speed automatic
This towing capacity is sufficient for most EV trailers and even flat-towing a disabled electric car (most EVs weigh 4,000–5,500 lbs). However, if you're towing an EV and a loaded cargo trailer, you'll approach the Tundra's limits quickly.
Aftermarket Wheel Options for the 5x150mm Pattern
The 5x150mm bolt pattern limits your aftermarket wheel selection significantly. Here's what's available and what to watch for:
- OEM Toyota wheels: The widest selection comes from other 2007–2021 Tundras and some Toyota Land Cruiser (200-series) models, which share the 5x150mm pattern.
- Aftermarket manufacturers: Brands like Fuel, XD Wheels, and Moto Metal offer limited 5x150mm options, primarily in 18-inch and 20-inch diameters.
- Custom forged wheels: Companies like HRE, Vossen, and Rotiform can forge wheels to 5x150mm spec, but at a premium ($600–$1,200+ per wheel).
- Spacers and adapters: Available but not recommended for load-bearing or high-speed use. They alter scrub radius and can accelerate wheel bearing wear.
If you're building a Tundra as a dedicated EV tow rig, prioritize load-rated wheels (Load Range D or E for LT-metric tires) over aesthetics. The extra weight of a trailer carrying an EV puts more stress on the rear axle and wheels than typical cargo.
Should You Keep the 2016 Tundra or Upgrade to an EV Truck?
If you're researching the 2016 Tundra bolt pattern because you're weighing whether to keep the truck or switch to an electric pickup, here's a practical decision framework:
Keep the 2016 Tundra if:
- You tow more than 8,000 lbs regularly (current EV trucks lose significant range under heavy towing — expect a 40–60% range reduction at max tow weight)
- You live in a rural area with limited DC fast-charging infrastructure
- Your truck is paid off and maintenance costs remain manageable
- You need a truck fewer than 5 days per month (an EV daily driver plus a gas truck for heavy tasks can be cost-effective)
Consider an EV truck if:
- Your daily driving is under 250 miles and you can charge at home
- You tow less than 5,000 lbs most of the time
- You want lower per-mile fuel costs (electricity at $0.13/kWh averages ~$0.04–0.05/mile vs. $0.18–0.22/mile for the Tundra's 13–15 MPG combined)
- You qualify for the federal clean vehicle tax credit (up to $7,500 for new EVs meeting MSRP, income, and battery-sourcing requirements under IRS §30D)
For context, the 2026 Ford F-150 Lightning starts around $55,000 (before incentives) and offers an EPA-estimated 240–320 miles of range depending on battery pack. The Rivian R1T starts around $70,000 with up to 410 miles of EPA range on the Max Pack. Both use 6-lug bolt patterns, so wheels are not interchangeable with your 2016 Tundra.
EV Truck Alternatives: Range, Charging, and Cost at a Glance
If you're cross-shopping, here's how the leading electric pickups compare on the metrics that matter most:
| Spec | F-150 Lightning (Ext. Range) | Rivian R1T (Max Pack) | Silverado EV (4WT) |
|---|---|---|---|
| EPA range | 320 mi | 410 mi | 440 mi |
| Battery capacity | ~131 kWh (NMC) | ~141 kWh (NMC) | ~200 kWh (NMC) |
| Max DC charge rate | 150 kW | 200+ kW | 350 kW |
| 10–80% charge time | ~41 min | ~30 min | ~20 min |
| 0–60 mph | ~4.0 sec | ~3.5 sec | ~4.5 sec |
| Max towing | 10,000 lbs | 11,000 lbs | 10,000 lbs |
| Starting MSRP | ~$55,000 | ~$70,000 | ~$55,000 |
| Bolt pattern | 6x135mm | 6x139.7mm | 6x139.7mm |
Note that real-world range while towing drops dramatically for all EV trucks. In testing by multiple outlets, towing a 5,000-lb trailer at highway speeds typically cuts range by 40–55%. That means the F-150 Lightning's 320-mile EPA estimate becomes roughly 150–180 miles under tow — a significant constraint for long-haul trailer trips.
Frequently Asked Questions
What is the bolt pattern on a 2016 Toyota Tundra?
The 2016 Toyota Tundra uses a 5x150mm (5x5.9-inch) bolt pattern with 5 lug nuts. The center bore is 110.1mm, and lug nuts should be torqued to 97 lb-ft (131 Nm).
Will 2016 Tundra wheels fit a Ford F-150 Lightning or Rivian R1T?
No. The 2016 Tundra uses a 5-lug 5x150mm pattern, while the F-150 Lightning uses a 6-lug 6x135mm pattern and the Rivian R1T uses a 6-lug 6x139.7mm pattern. The wheels are not interchangeable without adapters, and adapters are not recommended for safety and load-rating reasons.
What other vehicles share the 5x150mm bolt pattern?
The 5x150mm pattern is shared across 2007–2021 Toyota Tundras and the Toyota Land Cruiser 200-series (2008–2021). Some Lexus LX 570 models also use this pattern. It is not shared with any current-production electric vehicle.
Can I convert a 2016 Tundra to electric power?
Yes, aftermarket EV conversions are possible on body-on-frame trucks like the 2016 Tundra. Shops like EV West and Legacy EV offer conversion kits and custom builds. Costs typically range from $25,000 to $60,000+ depending on battery capacity and motor selection. The 5x150mm bolt pattern is retained unless the axle assemblies are swapped as part of the conversion.
Does the 2016 Tundra qualify for any EV tax credits?
No. The 2016 Tundra is a gasoline-powered vehicle and does not qualify for the federal clean vehicle tax credit (IRS §30D). Only new plug-in electric vehicles meeting specific MSRP caps ($80,000 for trucks/vans/SUVs), buyer income limits, and battery-sourcing requirements are eligible. Used EVs may qualify for up to $4,000 under the previously owned clean vehicle credit.
What's the best way to tow an EV behind a 2016 Tundra?
Use a flatbed trailer. Most EVs should not be flat-towed (all wheels on the ground) because the electric motor can generate uncontrolled current through regenerative braking, potentially damaging the battery or power electronics. A flatbed trailer keeps all four wheels off the ground and avoids this risk. The Tundra's 10,500-lb max tow rating is sufficient for most EVs plus a flatbed trailer (combined weight typically 6,000–8,000 lbs).
