If you are shopping for aftermarket wheels, winter tire sets, or replacement rims for the ninth-generation Malibu, knowing the correct bolt pattern for the 2013 Chevy Malibu is the essential first step. The 2013 Malibu uses a 5x120mm (5x4.72-inch) bolt pattern with a 56.56mm center bore and M12 x 1.5 lug nuts. This guide covers every wheel-mounting specification you need, along with practical fitment advice.
Note: The 2013 Chevy Malibu was a conventional gasoline-powered midsize sedan. This guide is provided as a reference resource for AutoEdgeView readers researching legacy models alongside our core electric and hybrid vehicle coverage.
2013 Chevy Malibu Bolt Pattern: Exact Specifications
The ninth-generation Chevrolet Malibu (introduced for the 2013 model year) rides on GM's Epsilon II platform, shared with vehicles like the Buick Regal and Opel Insignia. This platform dictates specific wheel-mounting hardware that differs from earlier Malibu generations.
| Specification | Value |
|---|---|
| Bolt Pattern (PCD) | 5x120mm (5x4.72 inches) |
| Number of Lugs | 5 |
| Center Bore | 56.56mm (56.6mm) |
| Lug Nut Thread Size | M12 x 1.5 |
| Lug Nut Torque Spec | 100 lb-ft (135 Nm) |
| Lug Seat Type | Cone (60° taper) — on most trims |
| Wheel Fastener Type | Lug nuts (not lug bolts) |
The 5x120mm bolt pattern means five lug holes arranged on a circle with a 120mm diameter. This is the same pattern used by many BMW models, the Chevrolet Camaro (2010+), and the Buick Regal — but it is not the same as the 5x115mm pattern found on the previous-generation (2008–2012) Malibu. Mixing these two patterns will result in improper fitment and potential vibration or safety issues.
Why the 2013 Malibu Bolt Pattern Changed from Prior Years
Owners coming from an eighth-generation Malibu (2008–2012) should be aware that the wheel specifications changed significantly with the 2013 redesign. The previous generation used a 5x115mm bolt pattern with a 70.3mm center bore. The Epsilon II platform adopted the 5x120mm pattern with a smaller 56.56mm hub bore.
This means wheels from a 2012 Malibu will not fit a 2013 model, and vice versa. If you are buying used wheels advertised for a "Malibu," always confirm the model year before purchasing.
OEM Wheel Sizes by Trim Level
The 2013 Malibu was offered across multiple trim levels (LS, LT, LTZ, and Eco), each with different factory wheel sizes. Understanding your trim's original equipment helps when sourcing replacements or upgrades.
| Trim Level | Wheel Size | OEM Tire Size | Offset (approx.) |
|---|---|---|---|
| LS | 17 x 8.0 inches | 225/55R17 | ~41mm |
| LT (1LT/2LT) | 17 x 8.0 inches | 225/55R17 | ~41mm |
| LTZ | 18 x 8.5 inches | 235/50R18 | ~41mm |
| Eco | 17 x 8.0 inches | 225/55R17 | ~41mm |
The most common OEM wheel size is 17x8.0 with approximately 41mm positive offset. If you are considering aftermarket wheels, staying within ±5mm of the factory offset (36mm–46mm range) will keep the scrub radius and steering geometry within safe tolerances. Going too aggressive with offset can cause the tire to rub against the fender liner or suspension components.
Aftermarket Wheel Fitment: What to Look For
When shopping for aftermarket wheels for the 2013 Malibu, every wheel must match these critical parameters:
- Bolt pattern: 5x120mm — no exceptions. Adapters exist for other patterns but introduce safety and vibration concerns.
- Center bore: 56.56mm or larger. If the aftermarket wheel has a larger bore (common with "hub-centric" aftermarket wheels sold in 73.1mm bore), you will need hub-centric rings (56.56mm to 73.1mm) to eliminate vibration.
- Offset: 35mm–45mm for a flush, safe fit without spacers.
- Wheel width: 7.5 to 8.5 inches works well with the factory tire sizes.
- Load rating: Ensure the wheel meets or exceeds the vehicle's gross axle weight rating. The 2013 Malibu's curb weight ranges from approximately 3,400 to 3,600 lbs depending on trim.
Chevrolet designed the 2013 Malibu's hub to be hub-centric, meaning the center bore of the wheel carries a portion of the load, not just the lug nuts. If you install a wheel with a bore larger than 56.56mm without hub-centric rings, the entire load transfers to the lug studs, which can cause vibration at highway speeds and accelerated stud wear. Always use hub-centric rings when the wheel bore exceeds 56.56mm.
Lug Nut Torque Specs and Installation Tips
Proper lug nut torque is critical for safety. The 2013 Chevy Malibu requires 100 lb-ft (135 Nm) of torque on all five lug nuts. Always follow these practices:
- Use a calibrated torque wrench — never an impact gun alone.
- Tighten in a star (crisscross) pattern to ensure even clamping force.
- Re-torque after the first 50–100 miles of driving on newly installed wheels.
- If using aftermarket lug nuts (e.g., for locking lugs), confirm they use the same M12 x 1.5 thread pitch and the correct seat type (cone/60° taper for most 2013 Malibu wheels).
- Never use anti-seize compound on lug studs — it changes the friction coefficient and can lead to over-torquing.
Compatible Vehicles Sharing the 5x120mm Bolt Pattern
One advantage of the 5x120mm bolt pattern is that it is shared across several popular vehicles. If you are sourcing used wheels, the following vehicles share the same 5x120 pattern — though center bore and offset must also be verified for each:
- Buick Regal (2011–2017)
- Chevrolet Camaro (2010–2024, most trims)
- Chevrolet Impala (2014–2020)
- Chevrolet SS (2014–2017)
- BMW 3 Series (most generations, E90/F30/G20)
- BMW 5 Series (most generations)
- Pontiac G8 (2008–2009)
Important caveat: While the bolt pattern matches, center bore diameters vary significantly. BMW wheels typically have a 72.56mm bore, which is larger than the Malibu's 56.56mm. Hub-centric rings are mandatory if using BMW wheels on a Malibu. Additionally, BMW wheels often have higher offsets (ET34–ET40), which may sit further inward on a Malibu.
Winter Wheel and Tire Setup Recommendations
Many 2013 Malibu owners in snow-belt states run a dedicated winter wheel-and-tire package. The most cost-effective approach is to downsize to 16-inch or 17-inch steel wheels with a narrower winter tire.
A popular winter setup for the 2013 Malibu:
- Wheel: 17x7.5 or 17x8.0 steel or alloy, 5x120mm, 56.56mm bore (or larger with rings)
- Tire: 215/60R17 or 225/55R17 winter-rated tire
- Benefit: Narrower tires cut through snow more effectively, and smaller sidewall heights maintain ride quality
Always confirm that the winter wheel clears the brake calipers. The 2013 Malibu LTZ with its larger front rotors may not clear some 16-inch steel wheels. Test-fit one wheel before purchasing a full set.
Frequently Asked Questions
What is the exact bolt pattern for the 2013 Chevy Malibu?
The 2013 Chevy Malibu uses a 5x120mm bolt pattern (also expressed as 5x4.72 inches). This is five lug holes on a 120mm bolt circle diameter. This pattern changed from the 2008–2012 Malibu, which used 5x115mm.
Will wheels from a 2012 Malibu fit a 2013 Malibu?
No. The 2008–2012 (eighth-generation) Malibu used a 5x115mm bolt pattern with a 70.3mm center bore. The 2013 (ninth-generation) Malibu switched to a 5x120mm pattern with a 56.56mm center bore. The two are not interchangeable without adapters, which are not recommended for daily driving.
What size are the lug nuts on a 2013 Malibu?
The 2013 Malibu uses M12 x 1.5 lug nuts with a 60-degree conical (tapered) seat. Torque specification is 100 lb-ft (135 Nm).
Can I use BMW wheels on my 2013 Chevy Malibu?
Many BMW wheels share the 5x120mm bolt pattern, but their center bore is typically 72.56mm — larger than the Malibu's 56.56mm hub. You would need 72.56mm-to-56.56mm hub-centric rings to prevent vibration. Offset and width must also be checked for clearance.
What is the center bore of the 2013 Malibu?
The center bore (hub bore) of the 2013 Chevy Malibu is 56.56mm. This is the diameter of the center hub that the wheel sits on. Any aftermarket wheel must have this exact bore or a larger bore used with hub-centric rings.
Where can I verify official wheel specifications for my Malibu?
The most reliable source is the owner's manual or the tire placard sticker located on the driver's side door jamb. You can also reference Chevrolet's official 2013 Malibu Owner's Manual for factory specifications. For aftermarket fitment, reputable wheel retailers like Tire Rack provide vehicle-specific fitment data.
